| Place of Origin: | CHINA |
|---|---|
| Brand Name: | YINTECH |
| Certification: | NA |
| Model Number: | DPM440C/DPM560C/DPM660C |
| Minimum Order Quantity: | 1 |
| Price: | $200,000-$600,000 |
| Packaging Details: | Standard export packaging |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 sets per month |
| Printing Style: | CMKY Duplex | Resolution: | 1200*1200DPI |
|---|---|---|---|
| Ink Type: | Water Based Pigment Ink | Max Media Width: | 440mm |
| Max Printing Width: | 432mm | Media Thickness: | 45 -165gsm |
| Media Type: | Digital Printing Paper, Inkjet Coating Paper, Newsprint, Wall Paper | ||
| High Light: | Digital Printer Inkjet Web Press,DPM330 Inkjet Web Press,DPM660 Book Printing Machine |
||
Yintech has always been focusing on developing, manufacturing and after-sales service of industrial inkjet technology, is committed to providing global users with high quality, intelligent, green, and world leading rotary inkjet digital printing solutions over the years.
To promote industry development, Yintech has opened the era of intelligent digital printing in the inkjet digital printing industry. While breaking technological monopoly and manufacturing pattern, Yintech has always insisted on independent innovation.
Specification
| Model | DPM440C/DPM560C/DPM660C |
| Printing style | CMYK duplex |
| Resolution | 1200×1200DPI |
| Ink type | Water based pigment ink |
| Water based pigment ink | 150m/min |
| Front-back registration | ±0.1 mm |
| Inkjet head | Drop-on-Demand piezoelectric nozzle |
| Drying | Infrared drying ( full automatic adjustment on printing speed ) |
| Operation interface | Visual operation interface |
| Max. media width | 440 mm/560mm/660mm |
| Max. printing width | 432 mm/540mm/648mm |
| Media thickness | 45-165g/㎡ |
| Media type | digital printing paper, inkjet coating paper, newsprint, wall paper, etc. |
| Max. roll diameter | 1.27 m |
| Mechanical platform | Max. 35 KW |
| Infrared drying | Max. 40KW |
| Digital control system | Max. 8 KW |
| Temperature | Range 22.5-27.5℃ Best working temperature 25℃ |
| Humidity | Range 40-70% Best working temperature 50-60%RH |
| Size | 11000*3500*2200 mm |
| Weight | 9500 KG |
Self-developed brand "FU CAI" series ink can highly match Print-On-Demand printing, and cost effective. The printing product is colorful, strong contrast, compatible with a variety of papers, durable, and no fading.
The digital printing equipment has a longer lifetime, outperforming traditional printing equipment, and a lower maintenance cost.
Advanced intelligent ink distribution system greatly reduces ink consumption while printing high-quality products.
Excellent design and high precision assembly technology have created a high quality paper conveying platform, which makes high-speed paper feeding more stable and motion control more precise, thus ensuring high quality printing.
Multi-bit deep network technology with own intellectual property rights enables printing quality to reach 1200dpi at a resolution of 600dpi, printing quality is as good as that of offset printing.
Unique nozzle driving technology makes sure each nozzle can work in high performance, so that the outer edges of the printing text and strokes are very round and smooth, therefore eliminating scattered inkjet dots and burrs very well.
High-precision nozzles splicing technology has been developed for many years, which make multiple nozzles splicing more simple and faster, so that printing pattern can achieve truly seamless connection.
