Printing Style: | CMKY Duplex | Resolution: | 1200*1200DPI |
---|---|---|---|
Ink Type: | Water Based Pigment Ink | Max Media Width: | 440mm |
Max Printing Width: | 432mm | Media Thickness: | 45 -165gsm |
Media Type: | Digital Printing Paper, Inkjet Coating Paper, Newsprint, Wall Paper | ||
High Light: | DPM560C Web Inkjet Printer,CMKY Duplex Web Inkjet Printer,DPM440C Inkjet Printing Machine |
Yintech has always been focusing on developing, manufacturing and after-sales service of industrial inkjet technology, is committed to providing global users with high quality, intelligent, green, and world leading rotary inkjet digital printing solutions over the years.
To promote industry development, Yintech has opened the era of intelligent digital printing in the inkjet digital printing industry. While breaking technological monopoly and manufacturing pattern, Yintech has always insisted on independent innovation.
Specification
Model | DPM440C/DPM560C/DPM660C |
Printing style | CMYK duplex |
Resolution | 1200×1200DPI |
Ink type | Water based pigment ink |
Water based pigment ink | 150m/min |
Front-back registration | ±0.1 mm |
Inkjet head | Drop-on-Demand piezoelectric nozzle |
Drying | Infrared drying ( full automatic adjustment on printing speed ) |
Operation interface | Visual operation interface |
Max. media width | 440 mm/560mm/660mm |
Max. printing width | 432 mm/540mm/648mm |
Media thickness | 45-165g/㎡ |
Media type | digital printing paper, inkjet coating paper, newsprint, wall paper, etc. |
Max. roll diameter | 1.27 m |
Mechanical platform | Max. 35 KW |
Infrared drying | Max. 40KW |
Digital control system | Max. 8 KW |
Temperature | Range 22.5-27.5℃ Best working temperature 25℃ |
Humidity | Range 40-70% Best working temperature 50-60%RH |
Size | 11000*3500*2200 mm |
Weight | 9500 KG |
Self-developed brand "FU CAI" series ink can highly match Print-On-Demand printing, and cost effective. The printing product is colorful, strong contrast, compatible with a variety of papers, durable, and no fading.
The digital printing equipment has a longer lifetime, outperforming traditional printing equipment, and a lower maintenance cost.
Advanced intelligent ink distribution system greatly reduces ink consumption while printing high-quality products.
