Applicable Industries: | Printing Shops, Advertising Company | Automatic Grade: | Automatic |
---|---|---|---|
Function: | Digital Printing | Printing Method: | Single Color Double-sided |
Resolution: | 600x600dpi/2bit600x1200dpi/2bit | Maximum Printing Speed: | 100 M/min |
Maximum Paper Width: | 660mm | Maximum Imaging Width: | 648mm |
Paper Type: | Digital Printing Paper, Inkjet Coated Paper, Newspaper | ||
High Light: | 100 M/Min Digital Inkjet Printer,Inkjet Coated Paper Digital Inkjet Printer,Mono Color Digital Inkjet Printing Machine |
Model | DMP660 |
Printing method | Single color/Dual color/CMYK double-sided |
Resolution | 600x600dpi/2bit600x1200dpi/2bit (maximum) |
Maximum printing speed | 100 m/min |
Overprint accuracy of front and back | ±0.3mm |
Sprinklers | On-demand piezoelectric sprinklers for industrial use |
Ink type | water-based pigment ink/water-based dye ink |
Drying method | infrared drying (with automatic speed adjustment function) |
Operation interface | infrared drying (with automatic speed adjustment function) |
Maximum paper width | 660mm |
Maximum imaging width | 648mm |
Paper weight | 45-165 g/m² |
Paper type | digital printing paper, inkjet coated paper, newspaper, wallpaper, rice paper, etc. |
Maximum roll diameter | 1.27 meters |
Mechanical platform | 380Vac, 15KW Max |
Infrared drying | 380Vac, 1-35KW Max |
Digital control system | 220Vac, 6KW Max |
Temperature range | 22.5-27.5°C, best working temperature 25°C |
Humidity range | 40-70%RH, best working humidity 50-60%RH |
Convenient and easy to use
• Print immediately after power-on, without wasting paper for start up.
• The output software can do continuous printing and inserting printing, which is convenient for arranging small jobs to be printed at any time, without stopping the machine and wasting paper, improving efficiency and saving production costs.
• By the concept of system engineering, the whole machine has a high degree of automation and better overall interoperability, which greatly reduces the number of operators, the difficulty of personnel management and the continuous increase of labor costs. Low consumption, high efficiency, stable and reliable operation.
Low production cost
• The maximum power of the inkjet system is 11.5KW, the maximum power of the cutting system is 22KW, and the maximum power of the entire system is 33.5KW. The actual production is about 12KW.
• The entire system is energy-saving and environmentally friendly, with low global power consumption, low overall operating costs, and production quality that meets users' current business needs, helping users obtain faster return on investment.
Exclusive technology
• Unique anti-broken line technology and ink supply technology that can guarantee the entire printing process without breaking line.
• The ink developed by independent technology has better printing adaptability, low power consumption drying performance and paper adaptability.
Scalability
• Can be upgraded to two-color printer.
• A variety of cutting programs are under development, and third-party cutting programs are supported.
More Affordable Inkjet POD Solution in the World!
• Market approved drop-on-demand industrial inkjet head technology
• Total roll-to-sheet print-on-demand inkjet print solution
• Short-run mono-color duplex or dual-color duplex book and periodical printing
• Flexibledeployment of structure, easily expand to dual-color duplex or spot color
• Sales price competitivity as lower as offset press
Have you or your customers been struggling the pain points in traditional offset book and periodical pringting?
• Huge waste of inventory / repertory / stock
• Environmental impact of waste and costly chemical treatment
• Long-term press ready time
• Smelly, noisy and dirty workshop harmful to worker's health
• Increasingly cost of human power
Today, you are having the right solution ever before from YINTECH, most affordable POD solution!
