128 diodes CTCP Plate Making Machine 43PPH Throughput 128 Channel

Basic Information
Place of Origin: China
Brand Name: Yinber
Certification: ISO9001~2000
Model Number: 9100B
Minimum Order Quantity: 1 set
Price: $20000~33000 per set
Packaging Details: Export Wooden Case for sea shipping well support the forklift, 5.0 CBM/set , 6 sets /20 GP.
Delivery Time: 20-30 days
Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 300 sets per Year
Rip/workflow Software: Harlequin /prinergy Loading System: Semi-auto/automatic
Driver Support: 1-bit Tiff Interface And Direct Workflow Driver,support Cip3/cip4 Laser Source Type: UV/405nm
Throughput: 43 PPH No. Of Lasers: 128 Diodes
High Light:

128 Diodes CTCP Plate Making Machine

,

43PPH Throughput CTCP Plate Making Machine

,

Automatic UV Plate Making Machine

128 Diodes CTCP Plate Making Machine 43PPH Throughput 128 Channel



UV CTcP Plate Making Machine 43 PPH Throughput 128 Channel 9100B

UV CTcP Plate Making Machine 43 PPH Throughput 128 Channel 9100B

Throughput : 17/22/27/33/43 plates/hour
Working environment requirements:
Max plate size: 1160x940mm min plate size: 350x400mm
Size: 2020x1000x930mm Net weight: 1500KG
Resolution: 2400dpi
Power requirements: AC220V, 50-60Hz 5.5KVA
Number of laser diodes: 32/48/64/96/128 channels
UV model: 9300/9500/9600/9900/9100 corresponding to UV laser diodes 32 /48/64/96/128 channels
Laser source: 830nm/405nm
CTP interface: 1-bit TIFF interface and workflow direct drive, support for CIP3/CIP4
Thermal model: 8300/8500/8600/8900/8100 corresponding to the thermal laser diodes 32 /48/64/96/128 channels
Plate loading/unloading system: manual/automatic/semi-automatic optional
Temperature: 20-25C, humidity: 40%-80%
Plate media gauge: 0.15-0.40mm various thermal plates/0.15-0.40mm various UV plates
